Product Details
＋
Order with any of our other products, enjoy FREE Add-On shipping (No extra shipping charge to be added)
Matching Bolts and Washers:
Matching installation tool:
This can be used for our . CAN NOT be used for our hairpin legs and pipe legs.
Features:
- Designed for use in hard woods, like oak, cherry, and maple.
- Superior hard wood holding power
- Ideal for use wherever assembly or disassembly could lead to thread erosion or stripping
- Easily installs with a screwdriver, bolt/jam nut, or optional drive tool
Installation:
E-Z Knife threaded inserts are typically installed with the slots up. The slots accommodate a screwdriver or E-Z LOK drive tool. For harder woods, screwdriver installation isn't practical. Installation can be accomplished with the drive tool or using a bolt and jam nuts. When using the bolt/jam nuts installation technique, the slotted end of the insert can be either up or down.Specifications:
| E-Z Lok P/N: | 400-4 |
| For Use in: | Hard Wood |
| Specific Material Use: | N/A |
| Sub-Category: | N/A |
| Style: | Knife Thread |
| Material: | Brass |
| System of Measurement: | Inch |
| Internal Thread: | 1/4-20 |
| External Thread: | N/A |
| Installed Length: | 0.5 |
| Drill Size: | 25/64 |
| Tap Size: | N/A |
| Minimum Full Thread Depth: | N/A |
| Installation Tool P/N: | 500-3 |
